Condition: New
|
Ports | 24x 1G/10G SFP+ ports (LRM + MACsec) 2x 10G/25G/50G1 SFP ports 2x 10G/25G SFP ports (MACsec) 1x USB-C Console Port 1x RJ Console Port 1x OOBM port 1x USB Type A Host port | |
| Power Supplies | 2 field-replaceable, hotswappable power supply slots 1 minimum power supply required (ordered separately) Supported PSUs JL085A JL757A PSU | |
| Fans | The switch has two fan tray slots and comes with two fan trays installed. Min 2 fan trays required. Fan trays are field replaceable and hotswappable. Each fan tray contains two fans. |
|
|
Mounting and Enclosure | Mounts in an EIA- standard 19 in. telco rack or equipment cabinet. Horizontal surface mounting only. 2-post rack kit included. | |
| Additional Specifications | CPU | Quad Core ARM Cortex™ A72 @ 1.8GHz |
| Memory and Flash | 8 GB DDR4 32 GB eMMC | |
| Packet Buffer | 16 MB | |
| Performance | System switching capacity | 880 Gbps |
| System throughput capacity | 660 Mpps | |
| Model switching capacity | 880 Gbps | |
| Model throughput capacity | 654 Mpps |
|
|
Mounting and Enclosure | Mounts in an EIAstandard 19 in. telco rack or equipment cabinet. Horizontal surface mounting only. 2-post rack kit included. |
|
