Ports |
48 RJ-45 autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASE-TX, IEEE 802.3ab Type 1000BASE-T); Duplex: 10BASE-T/100BASE-TX: half or full; 1000BASE-T: full only |
|
|
1 extended module slot |
||
|
4 fixed 1000/10000 SFP+ ports |
||
|
1 RJ-45 serial console port |
||
|
Physical characteristics |
Dimensions |
17.32(w) x 16.81(d) x 1.72(h) in (44.0 x 42.7 x 4.36 cm) (1U height) |
|
Weight |
18.74 lb (8.5 kg) |
|
|
Memory and processor |
2048 MB SDRAM; Packet buffer size: 8 MB, 512 MB flash |
|
|
Performance |
Latency |
4.02 µs (Store and Forward) (64-byte packets) |
|
Throughput |
up to 190 Mpps |
|
|
Routing/Switching capacity |
256 Gbps |
|
|
Routing table size |
16000 entries |
|
|
MAC address table size |
32000 entries |
|
We ship all products according to manufacturer specifications. If the manufacturer does not include an option as standard with the product (power supply, fan tray etc) we do not either unless specifically stated. If you are have questions regarding what is included with a product, please contact us.
