Specs:
-2.4-GHz (600 Mbps max) and 5-GHz (1.3 Gbps max)
radios, each with 3x3 MIMO and three integrated omni-directional downtilt antennas.
-AP type: Indoor, dual radio, 5 GHz 802.11ac and
2.4 GHz 802.11n
2.4 GHz 802.11n
-Support for up to 256 associated client devices per radio,
and up to 16 BSSIDs per radio
and up to 16 BSSIDs per radio
-Power sources sold separately
-Power over Ethernet (PoE): 48 Vdc (nominal) 802.3af or
802.3at-compliant source
802.3at-compliant source
-Six integrated downtilt omni-directional antennas
for 3x3 MIMO with maximum antenna gain of 3.5 dBi
in 2.4 GHz and 4.5 dBi in 5 GHz. Built-in antennas are
optimized for horizontal ceiling mounted orientation
of AP-225. The downtilt angle for maximum gain is
approximately 30 degrees
for 3x3 MIMO with maximum antenna gain of 3.5 dBi
in 2.4 GHz and 4.5 dBi in 5 GHz. Built-in antennas are
optimized for horizontal ceiling mounted orientation
of AP-225. The downtilt angle for maximum gain is
approximately 30 degrees
-Two 10/100/1000BASE-T Ethernet network interfaces (RJ-45)
-Auto-sensing link speed and MDI/MDX
-Load balancing support to achieve platform throughput
greater than 1 Gbps
-Auto-sensing link speed and MDI/MDX
-Load balancing support to achieve platform throughput
greater than 1 Gbps
-802.3az Energy Efficient Ethernet (EEE)
-PoE-PD: 48 Vdc 802.3af PoE or 802.3at PoE+
-DC power interface, accepts 1.7/4.0mm center-positive circular plug with 9.5 mm length
-USB 2.0 port (Type A connector)
-Serial console interface (RJ-45)
-Visual indicators (LEDs): Power/system status, Ethernet link status (2x; ENET0, ENET1), Radio status (2x; RAD0, RAD1)
-Kensington security slot
-Reset button
-PoE-PD: 48 Vdc 802.3af PoE or 802.3at PoE+
-DC power interface, accepts 1.7/4.0mm center-positive circular plug with 9.5 mm length
-USB 2.0 port (Type A connector)
-Serial console interface (RJ-45)
-Visual indicators (LEDs): Power/system status, Ethernet link status (2x; ENET0, ENET1), Radio status (2x; RAD0, RAD1)
-Kensington security slot
-Reset button
Included with AP:
- Mounting brackets (2) for attaching to 9/16-inch or
15/16-inch T-bar drop-tile ceiling
- Mounting brackets (2) for attaching to 9/16-inch or
15/16-inch T-bar drop-tile ceiling
Manufacturer Part Numbers: JW242A, APIN0225, IAP-225-US, JW242-61001
