The Aruba CX 6200 Switch Series is a next-gen family of stackable access switches ideal for enterprise branch offices, campuses, and SMB networks. With a cloud-centric design that combines a fully programmable OS with the Aruba Network Analytics Engine, the Aruba CX 6200 extends industry-leading monitoring and troubleshooting capabilities to the access layer. Support of Aruba NetEdit and the Aruba CX Mobile App verify that configurations are flawless and easy to deploy. Make your network ready for tomorrow’s unpredictable demands with a powerful Aruba Gen7 ASIC architecture to deliver fast, non-blocking performance. Aruba Virtual Stacking Framework (VSF) allows for stacking of up to 8 switches, providing scale and simplified management. This series has built-in high speed uplinks and up to 740W of PoE to support IoT devices such as security cameras and wireless APs.
Next-generation family of stackable access switches ideal for enterprise branch offices, campuses and SMB networks. 48x 10/100/1000BASE-T Class 4 PoE Ports and 4x 100M/1/10G SFP+ ports.
Power Consumption: Idle: 42W, 100% Traffic Rate: 60W
Input Voltage: 100V-120V/200V-240V
External I/O Ports: 48x ports 10/100/1000BASE-T Class 4 PoE Ports (supporting up to 30W per port), 4x 100M/1/10G SFP+ ports, 1x USB-C Console Port, 1x RJ-45 Console Port, 1x OOBM, 1x USB Type-A Host port
Latency: 1 Gbps: 3.3 μSec, 10 Gbps: 2.3 μSec
MAC Table Capacity: 32,768
CPU: Quad Core ARM Cortex™ A72 @ 1.8GHz
Memory and Flash: 8 GB DDR4, 16 GB eMMC
PoE Capability: Up to 740W of Class 4 PoE Power
